ماژول کنترل دور موتور DC خروجی PWM با ولتاژ 6V الی 28V

• محدوده ولتاژ: 6 ولت تا 28 ولت
• حداکثر جریان: 3آمپر
• خروجی PWM
• دارای ولوم جهت کنترل دور موتور

Instruction

This DC Motor Speed Controller lets you control the speed of a DC motor using a Pulse Width-Modulated (PWM) DC voltage with a Duty Cycle fully adjustable from 5%-100%. It can be used to drive all DC Brushed Motors that work between 6V-28V DC and consume upto 3A of current.

Specification

Input supply voltage:6V-28VDC
The maximum output power: 80W
The maximum continuous output current :3A
Duty Cycle adjustable:5%-100%
PWM Frequency: 500khz
